A transformer with 1200 turns in the primary circuit and 120 turns in the secondary circuit has its primary circuit connected to a 400V a.c....

A transformer with 1200 turns in the primary circuit and 120 turns in the secondary circuit has its primary circuit connected to a 400V a.c. source. It is found that when a heater is connected to the secondary circuit, it produces heat at the rate of 600W. Assuming 100% efficiency, determine the:
i) voltage in the secondary circuit.
ii) current in the primary circuit.
iii) current in the secondary circuit.

---

---

sharon kalunda answered the question on September 30, 2019 at 11:20
