A bullet of mass 2g is fired horizontally into a block of wood of mass
498g. The block is suspended by a light inextensible string so...
(Solved)
A bullet of mass 2g is fired horizontally into a block of wood of mass
498g. The block is suspended by a light inextensible string so that it is able to move in a vertical plane. The block and the bullet move together through a vertical distance of 8.6cm as shown in figure below.
I. Calculate the change in gravitational potential energy of the block and bullet.
II. Calculate the initial velocity of the block and bullet after they start moving together.
III. Determine the speed of the bullet before the impact with the block.
Date posted:
June 4, 2019
.
Answers (1)
-
State the SI unit of momentum as used in Physics.
(Solved)
State the SI unit of momentum as used in Physics.
Date posted:
June 4, 2019
.
Answers (1)
-
The Figure below shows a velocity-time graph for a steel ball falling
through a viscous fluid.
Explain the nature of the curve in;
(i) section PQ.
(ii) section QR.
(iii)...
(Solved)
The Figure below shows a velocity-time graph for a steel ball falling
through a viscous fluid.
Explain the nature of the curve in;
(i) section PQ.
(ii) section QR.
(iii) If the graph shown above is of a ball falling through water, sketch on the same axis a graph for the ball falling through glycerine.
Date posted:
June 4, 2019
.
Answers (1)
-
The Figure 11 below shows a hydraulic lift supporting a load of 150kg. Its cross-sectional areas A1 and A2 are 0.02m2 and 0.4m2 respectively. The...
(Solved)
The Figure 11 below shows a hydraulic lift supporting a load of 150kg. Its cross-sectional areas A1 and A2 are 0.02m2 and 0.4m2 respectively. The length of the effort arm is 1m and the length of the plunger from the pivot is 0.4m.
Determine:
(i) the pressure exerted by 150kg mass.
(ii) the pressure exerted by F1 on the smaller piston.
(iii) the force F1.
(iv) the applied force, Fe.
(v) the mechanical advantage.
(vi) the velocity ratio of the system.
(v) the efficiency of the system.
Date posted:
June 4, 2019
.
Answers (1)
-
A stone of mass 0.5kg is attached to a string of length 0.5m which will break if the tension exceeds 20N. The stone is whirled...
(Solved)
A stone of mass 0.5kg is attached to a string of length 0.5m which will break if the tension exceeds 20N. The stone is whirled in a vertical plane, the axis of rotation being above the ground, as shown in the Figure below.
The angular velocity is gradually increased until the string breaks.
(a) In what position is the string most likely to break?
(b) At what angular velocity, w, will the string break?
Date posted:
June 4, 2019
.
Answers (1)
-
A stone is thrown with a horizontal velocity u from the top of a building of height 125m so as to hit a target on...
(Solved)
A stone is thrown with a horizontal velocity u from the top of a building of height 125m so as to hit a target on the ground 75m from the base of the building as shown in Figure below.
Calculate:
(i) the time taken for the stone to hit the target.
(ii) the horizontal velocity, u, of the stone.
Date posted:
June 4, 2019
.
Answers (1)
-
The Figure below shows a planet Venus orbiting the sun in a circular orbit
at constant speed.
(i) State what provides the centripetal force.
(ii) Indicate the...
(Solved)
The Figure below shows a planet Venus orbiting the sun in a circular orbit
at constant speed.
(i) State what provides the centripetal force.
(ii) Indicate the direction of centripetal force on the planet.
Date posted:
June 4, 2019
.
Answers (1)
-
Explain how greenhouse effect increase the average temperate of the earth.
(Solved)
Explain how greenhouse effect increase the average temperate of the earth.
Date posted:
June 4, 2019
.
Answers (1)
-
The bicycle pump shown in Figure below is one of the applications of pressure in
gases.
Explain how the leather washer functions during;
(a) backstroke
(b) forward stroke
(Solved)
The bicycle pump shown in Figure below is one of the applications of pressure in
gases.
Explain how the leather washer functions during;
(a) backstroke
(b) forward stroke
Date posted:
June 4, 2019
.
Answers (1)
-
The diagram below shows a spiral spring when not compressed and when
compressed by a mass of 4.0kg.
Determine the elastic potential energy stored by the compressed...
(Solved)
The diagram below shows a spiral spring when not compressed and when
compressed by a mass of 4.0kg.
Determine the elastic potential energy stored by the compressed spring in (b).
Date posted:
June 4, 2019
.
Answers (1)
-
A smooth wooden plane is inclined at an angle of 300 to the horizontal as shown in Figure 5 below. An object of mass 10kg...
(Solved)
A smooth wooden plane is inclined at an angle of 300 to the horizontal as shown in Figure 5 below. An object of mass 10kg is pulled steadily up the plane by a force of 60N. Determine;
(a) the velocity ratio of the inclined plane.
(b) efficiency of the system.
Date posted:
June 4, 2019
.
Answers (1)
-
The figure below shows a rubber bladder filled with air and fixed at the bottom of a
water container and held with a cotton string.
State and...
(Solved)
The figure below shows a rubber bladder filled with air and fixed at the bottom of a
water container and held with a cotton string.
State and explain the observation made when water is heated gently for a few
minutes.
Date posted:
June 4, 2019
.
Answers (1)
-
An immersion heater consumes a voltage of 240V and a current of 10A. If it is used to heat 5kg of water at 200C, find...
(Solved)
An immersion heater consumes a voltage of 240V and a current of 10A. If it is used to heat 5kg of water at 200C, find the final temperature of water after 7 minutes. (Take the specific heat capacity of water = 4200 J/kgk)
Date posted:
June 4, 2019
.
Answers (1)
-
A student observed some pollen grains on the surface of water in a beaker with the
help of hand lens as shown below.
(a) State the observation...
(Solved)
A student observed some pollen grains on the surface of water in a beaker with the
help of hand lens as shown below.
(a) State the observation made.
(b) Explain the observation in (a) above.
(c) What conclusion can be drawn from the above experiment.
Date posted:
June 4, 2019
.
Answers (1)
-
The figure below shows a force of 40N acting on a body of mass 4kg. The coefficient of friction between the surfaces is 0.05.
Determine the...
(Solved)
The figure below shows a force of 40N acting on a body of mass 4kg. The coefficient of friction between the surfaces is 0.05.
Determine the acceleration of the body.
Date posted:
June 4, 2019
.
Answers (1)
-
Define a free fall.
(Solved)
Define a free fall.
Date posted:
June 4, 2019
.
Answers (1)
-
The figure below shows a ray of light incident at an angle of 35.60 at point D on the first face of a glass prism...
(Solved)
The figure below shows a ray of light incident at an angle of 35.60 at point D on the first face of a glass prism ABC. The refractive index of the prism is 1.6.
(i) Determine the angle of refraction at point D.
(ii) Find the angle of incidence of the refracted ray on the face AC to 1 decimal point.
(iii) Complete the ray diagram to show the emergent ray from the face AC.
(iv) State two conditions necessary for total internal reflection to occur.
Date posted:
June 3, 2019
.
Answers (1)
-
A heater is rated 2000W is used to heat water for 5 hours. Calculate the cost of electricity at Ksh.6.70 per unit.
(Solved)
A heater is rated 2000W is used to heat water for 5 hours. Calculate the cost of electricity at Ksh.6.70 per unit.
Date posted:
June 3, 2019
.
Answers (1)
-
An object of height 10.5cm stands before a diverging lens of focal length 20cm and a distance of 10cm from the lens. Determine;
(i) image distance....
(Solved)
An object of height 10.5cm stands before a diverging lens of focal length 20cm and a distance of 10cm from the lens. Determine;
(i) image distance.
(ii) height of the image.
(iii) magnification.
Date posted:
June 3, 2019
.
Answers (1)
-
The graph below show stopping potential Vs against frequency f. (Take C = 3.0 x 108ms¯¹).
Use the graph to determine:-
(i) the threshold wavelength.
(ii) Planck’s...
(Solved)
The graph below show stopping potential Vs against frequency f. (Take C = 3.0 x 108msˉ¹).
Use the graph to determine:-
(i) the threshold wavelength.
(ii) Planck’s constant.
(iii) the work function of the metal.
Date posted:
June 3, 2019
.
Answers (1)
